Monroe® 74025 Shock Absorber
Manufacturer #74025
Monroe® 74025 Shock Absorber
Manufacturer #74025
$76.46
$107.04
Save $30.58 (29%)
(2) In Stock
Get it between Wed, Aug 20 - Fri, Aug 22, 2025
Does This Fit? Add Vehicle to Guarantee Fit!
Add vehicleFast Shipping
We ship fast so you can get on the road that much faster100% Safety
Only secure payments| SKU | TS74025 |
|---|---|
| Brand | Monroe® |
| Part Name | Shock Absorber |
| Part | # 74025 |
| Quantity Per Vehicle | 1 |
| Pack of | 1 |
| Condition | New |
- Magnum Rear; Front Suspension Shock Absorber
- Monroe Magnum 74025 Rear; Front Suspension Shock Absorber
- Tough Monroe® Magnum® shock absorbers for transit buses deliver a firm, controlled ride for greater stability and increased driver and passenger comfort. Magnum transit bus shocks are designed to meet or exceed demanding OE manufacturer specifications.
- FOR HARDWORKING TRANSIT BUSES -- Designed to handle the demands of high mileage and severe use transit buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/4-in. reserve tube holds more fluid to improve performance (when required)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore allows valve finetuning by allowing more hydraulic fluid to dissipate heat for better control
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (when required)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
| Compressed Length (IN) | 15.62 |
|---|---|
| Compressed Length (MM) | 396.7 |
| Extended Length (IN) | 24.52 |
| Extended Length (MM) | 622.8 |
| Travel Length (IN) | 8.9 |
| Travel Length (MM) | 226.1 |
| Lower Mount Type | Loop bushing mount - 1' bushing id x 1.3/4' bushing oal |
| Lower Mount Code | L4 |
| Upper Mount Type | Loop bushing mount - 1' bushing id x 1.3/4' bushing oal |
| Upper Mount Code | L4 |
| Shock Absorber Rod End Measuring Point | Center of loop |
| Shock Absorber Body End Measuring Point | Center of loop |
| Gas Charged | No |
| Internal Rebound Bumper | No |
| Parts Pack(s) | None |
| Color | Black |
| Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Diameter (MM) | 80 |
| Dust Shield Diameter (IN) | 3.15 |
| Dust Shield Material | Metal |
| Shock Absorber Bore Size (MM) | 44.5 |
| Shock Absorber Bore Size (IN) | 1.75 |
| Includes Bump Stop | No |
| Hydraulic Lockout | Yes |
| Part Description | Shock absorber |
| Adjustable Damping | No |
| Internal Construction Type | Twin tube |
| Shaft Diameter (MM) | 18 |
