LUK® DMF138 Clutch Flywheel
Manufacturer #DMF138
LUK® DMF138 Clutch Flywheel
Manufacturer #DMF138
$341.71
$478.39
Save $136.68 (29%)
(4) In Stock
Get it between Thu, Aug 21 - Mon, Aug 25, 2025
E.P.A. Compliant Converters are not legal for sale or use in California or Colorado. Restrictions apply in New York and Maine.
Does This Fit? Add Vehicle to Guarantee Fit!
Add vehicleFast Shipping
We ship fast so you can get on the road that much faster100% Safety
Only secure payments| SKU | LKDMF138 |
|---|---|
| Brand | LUK® |
| Part Name | Clutch Flywheel |
| Part | # DMF138 |
| Quantity Per Vehicle | 1 |
| Pack of | 1 |
| Condition | New |
-
Hyundai
-
Kia
- LuK DMF Manu
- LuK: Don’t gamble – stay with the original LuK DMF! The LuK DMF prevents damages solid flywheels may cause. The LUK Dual Mass Flywheel (DMF) is individually fine-tuned for every type of car. The risks of using solid flywheels are numerous – from increased wear of engine mounts through gearbox failure to damaged crankshafts.
| Cup depth, secondary flywheel (inch) | -0.5236 |
|---|---|
| Cup depth, secondary flywheel (mm) | -13.3 |
| Ring Gear To Friction Surface (inch) | 0.9646 |
| Ring Gear To Friction Surface (mm) | 24.5 |
| Overall Casting O.D. (inch) | 10.9055 |
| Overall Casting O.D. (mm) | 277 |
| I.D. for Pilot (inch) | 0.5906 |
| I.D. for Pilot (mm) | 15 |
| Number of teeth, starter ring gear | 110 |
| Bolt hole PCD crankshaft (inch) | 2.6772 |
| Bolt hole PCD crankshaft (mm) | 68 |
| Crank Hole Dia. (inch) | 0.5 |
| Crank Hole Dia. (mm) | 12.7 |
| Bolt hole PCD clutch pres.plte (inch) | 10.0787 |
| Bolt hole PCD clutch pres.plte (mm) | 256 |
| Dowel hole diameter (inch) | 0.315 |
| Dowel hole diameter (mm) | 8 |
| Ring Gear Chamfer matches OE | Ring gear chamfer matches oe |
| Flywheel Friction Surface Inner diameter (inch) | 5.7874 |
| Flywheel Friction Surface Inner diameter (mm) | 147 |
| Flywheel Thickness [mm] (inch) | 2.2598 |
| Flywheel Thickness [mm] (mm) | 57.4 |
| Bolt Hole Pattern | 2 |
| Dowel Hole Pattern | 5 |
| Centering diameter / dowel hole (inch) | 10.0787 |
| Centering diameter / dowel hole (mm) | 256 |
| Flange Thickness (inch) | 0.3622 |
| Flange Thickness (mm) | 9.2 |
| Ring Gear Thickness (inch) | 0.5472 |
| Ring Gear Thickness (mm) | 13.9 |
| Flywheel friction surface outer diameter (inch) | 9.4488 |
| Flywheel friction surface outer diameter (mm) | 240 |
| Ring Gear Major Dia. (inch) | 11.0748 |
| Ring Gear Major Dia. (mm) | 281.3 |
| Ring Gear Mounting O.D. (inch) | 10.0984 |
| Ring Gear Mounting O.D. (mm) | 256.5 |
